VLPCB-IND1 Industrial Controller
A 7.5 kW Infrared Controller offering a simple cost effective solution for controlling temperature and power percentage for small industrial applications.
Available as Single or 3-Phase
Controlled, Efficient Heating
- For use in indoor applications
- Powder coated cast aluminium casing
- IP20 rated
- Temperature & Power settings
- 3 Memory setting options
- 3 Switchable outputs
- Single-Phase
- Easy installation
- 3-Phase version also available
| Input Voltage | 220 - 240V Single Phase, 50Hz |
| Max. Power Rating | 7.kkW |
| Max. Current Rating | 32A |
| Max. Load Per Output Terminal | 10.5A |
| IP Rating | IP20 |
| Operating Temp | -20 to +50 Degrees C |
| Weight | 0.6Kg (excl. Input Cables) |
| Dimensions | 210 Wide x 30 High x 130 mm Deep |
| (excl. Switch & Cable Glands) |
- Temperature range setting: 10 to 300 Degrees C
- Power range setting: up to 100%
- Thermocouple supplied as standard
- Optional extra - pyrometer
| Code | Finish | Colour |
|---|---|---|
| VLPCB-IND1 | Casing Only | RAL7032 Pebble Grey |
Suitable for any electrical device with load up to 7.5kW
